M320TF32" 4K UHD Color Surgical Display with 3D LUT profile selection
The M320TF has been phased out and replaced by the W32L100-PTA1. For more information, please get in touch with us.
- 32" Display with UHD 4K (3840 x 2160) native resolution, Color Surgical Display
- Thin and compact design with impact resistant screen
- 3D Look Up Table (LUT) providing rich and deep depth perception
- Built-in stereo speakers and common 3.5mm input and output jacks, will alleviate the issue for an additional speaker system
- Fanless and ventless design, easy-to-clean
- Compatible with existing imaging systems
- Antimicrobial Surface Coating
- 3D LUT profile selection, optional DICOM
32" 4K UHD Color Surgical Display with 3D LUT profile selection
Winmate's 4K UHD Healthcare Display complies with several international healthcare and patient safety standards UL60601/ISO13485. These displays can be found in health centers, clinical research laboratories, and patient care units. Plus, the antimicrobial housing helps to prevent the spread of bacteria and contaminants.
Wide Viewing Angle
The wide-view angle found in surgical displays allows health professionals to see accurate and consistent images from different angles. Surgical displays often have two or more people viewing the screen simultaneously from different positions in the room.
Winmate's 4K UHD Healthcare Display supports multi-tasking and simultaneous image viewing. The picture-in-picture (PIP) function separates the screen into two parts, where one source device is displayed on the main screen while another is shown as an inset window. The picture-by-Picture (PBP) function separates the screen in half by simultaneously displaying the output from two different source devices.
Convenient User Controls
Physical buttons or PCAP multi-touch support enables quick access to display settings, making these healthcare-grade displays a reliable solution where human-interface interaction is involved. Accessing menu settings through physical buttons is not an option in sterilized environments; hence the infrared remote control offers the ability to manage the display settings remotely to prevent cross-contamination.
Backlight Sensor and Ambient Light Sensor
Healthcare-grade displays can typically detect and adjust backlight levels. A backlight sensor continuously monitors and stabilizes the brightness/ luminance output to project stable image viewability. The ambient light sensor helps the Human Visual System (HVS) to adapt to changing light conditions for a consistent user experience.
3D LUT profile selection, optional DICOM
DICOM Optional: Digital Imaging and Communications in Medicine (DICOM) is the standard for the communication and management of medical imaging information and related data. DICOM is most commonly used for storing and transmitting medical images enabling the integration of medical imaging devices such as scanners, servers, workstations, printers, network hardware, and picture archiving and communication systems (PACS) from multiple manufacturers. It has been widely adopted by hospitals and is making inroads into smaller applications like dentists and doctors' offices.
Touch / Glass
Projected Capacitive Multi Touch Screen AR Glass (Optional)
350 nits 700 nits(Optional)
708.48 x 398.52 mm
10% to 90% RH, non-condensing
0°C to 35°C
-20 °C to 60 °C
IEC 60601-1:2005 + A1:2012 (Ed. 3.1) IEC 60601-1-6:2010 + A1:2013 (Ed. 3.1) IEC 62366:2007 + A1:2014 (Ed. 1.1) ANSI/AAMI ES60601-1:2005/A1:2012 and C1:2009/(R)2012 and A2:2010/(R)2012 CAN/CSA-C22.2 No.60601-1:14 EN 60601-1-2:2015, IEC 60601-1-2:2014 (Ed. 4.0) EN 55032/EN 55024, FCC part 15B EN 62368-1:2014 RoHS-2, REACH, WEEE compliant
1 x USB 2.0
1 x RS-232
1 x RJ-11
1 x Dual DVI In 1 x DP 1.2 Out 1 x DP 1.2 In 1 x VGA In 1 x SDI in 1 x SDI out 1 x HDMI 1.4 (Optional) 1 x HDMI 2.0 (Optional)
1 x Mic In 1 x Line Out 2 x Speaker
Capacitive OSD : Power On/Off, On Screen Display Menu,Enter,Brightness Control (-/+)
777.58 x 477.62 x 48 mm
Metal Housing with Aluminum Bezel
Remote Control User Manual M4 VESA Mounting Screws 24 Volt Power Supply Power Cable 1.8m VGA Cable DVI Cable 1.8 m SDI Cable DC Jack to Open Wire Cable
USB Cable for Touch (Optional)
24V DC in
