R15IB3S-65EX

15" Intel® Celeron® N2930 ATEX Panel PC

R15IB3S-65EX

15" Intel® Celeron® N2930 ATEX Panel PC
  • KEY FEATURES
  • 15” 1024 x 768, PCAP touchscreen
  • Class 1, Division 2 & ATEX Zone 2 & IECEx Zone 2 device certified for hazardous area application
  • Intel® Celeron® Processor N2930
  • Fanless design with streamlined enclosure for highly efficient heat dissipation
  • Wide operating temperature -20˚C to 50˚C
  • CERTIFICATIONS
  • CUL TS TD0700KL MIL-STD 810G IP65 ATEX & C1D2 FCC CE
Overview
Specification
Certified for Hazardous Locations

Certified for Hazardous Locations

The R15IB3S-65EX is ATEX Zone 2 certified computers for remote data collection, process visualization, and control. Suitable for the deployment in ATEX Zone, where safety is the priority.


Real-Time Production Monitoring and Control

Real-Time Production Monitoring and Control

Take production control to the next level with real-time data monitoring and visualization. The R15IB3S-65EX is a stainless ATEX panel PC with a set of features designed to withstand industrial use in hazardous locations and extreme temperatures while providing high tech solutions that increase productivity, improve safety, and reduce operational costs.


Stable Performance and Fanless Thermal System

Stable Performance and Fanless Thermal System

The processing power comes from Intel® Celeron® N2930 processor paired with genuine Intel graphics for stable computing performance and ultra-low power consumption. Fanless, streamlined enclosure for highly efficient heat dissipation.


Ultimate Touch Experience

Ultimate Touch Experience

Enhance customer experience with PCAP touch that supports multi-touch and can easily be controlled by fingers. Enjoy every touch and convenience when using the R15IB3S-65EX, and experience the ultimate durability in some of the most demanding applications, such as a control panel of a drilling rig.


Suitable for Wide Working Temperatures

Suitable for Wide Working Temperatures

The R15IB3S-65EX ATEX panel PC is rated for a wide temperature use -20˚C to 50˚C and suitable for operating in outdoor or hazardous environments, whether there are blistering hot or cold temperatures.

System Specification

Processor

Intel® Celeron® N2930 (2M Cache, up to 2.16 GHz)

Memory

1 x SO-DIMM, DDR3L 1600 MHz, 4GB 8GB (Optional)

Storage

1 x mSATA SSD 64GB. mSATA SSD up to 512GB. (Optional)

Ethernet controller

2 x Intel® Ethernet Controller I210-AT

Security

TPM 2.0

Operating System

Windows 7 Embedded Systems (Optional) Windows 10 IoT Enterprise (Optional) Linux Ubuntu 18.04 (Optional)

Display

Touch / Glass

Projected Capacitive Multi Touch Screen Bonding With Panel

Size

15.0 inches

Resolution

1024x768

Panel Brightness

550 nits 1000 nits(Optional)

Contrast Ratio

2000:1

View Angles

88,88,88,88

Mechanical

Dimension

396 x 310 x 49 mm

Mounting

VESA Mount

Enclosure

Stainless Housing

Cooling System

Fanless design

Environment

Operating Humidity

10% to 95% (non-condensing)

Operating Temperature

-20~50°C

Storage Temperature

-20~50°C

Shock

MIL-STD-810G Method 516.6

Vibration

MIL-STD-810G Method 514.6

Drop

MIL-STD-810G Method 516.6

IP rating

IP65

Certification

Certification

CE, FCC IECEx Zone 2 Certication (applied for) nA IIC T4 Gc -20 °C ≤ Ta ≤ +50 °C ATEX Zone 2 Certication (applied for) II 3 G Ex nA IIC T4 Gc -20 °C ≤ Ta ≤ +50 °C UL Listing Certication (applied for) Class I, Division 2, Groups A, B, C, and D

IO Ports

USB Port

1x M12 type connector for 2 x USB2.0

Serial Port

1 x M12 connector for RS232/422/485 (Default RS232)

LAN

1 x M12 type connecctor gor Giga LAN

Indicator

1 x LED Indicator for power 1 x LED Indicator for storage

Control

Button

1 x Power Button 1 x Reset Button

Accessory

Accessory

100~240V AC to DC Power Adapter with M12 Connector Power Cord M12 Type Power Cable M12 Type RS232 Male Cable M12 Type USB Female Cable M12 Type LAN Cable RJ45 female-female converter USB Adapter (USB type A to type B) Driver CD & Manual VESA screws
