R15IK3S-67C3(HB)15" Intel® Core™ i5 G-WIN Full IP67 Panel PC
KEY FEATURES
- 7th Generation Intel® Core™ i5-7200U (kaby Lake) 2.5GHz (turbo to 3.1GHz)
- High Quality 15" Panel, 1024 x 768 resolution, 300 nits (Optional for 1000 nits)
- IP67 Dust/ Water proof design with VESA mount
- Aluminum Die-Casting Housing with Anti-Corrosion Treatments
- Build in ambient Light sensor
- Wide Range 9 to 36V DC Input with isolation
- Optional 6-60V DC Input, and Optional for Ignition On/Off delay
- 5 Wire Resistive Touch / Anti-Reflective Protection Glass (Optional)
- Optional HB/Sunlight Readable up to 1000 nits, 15inch G-WIN Full IP67 Panel PC
- CERTIFICATIONS
-
-45-L4-I.png "R15IK3S-67C3(HB) | 15\" Intel® Core™ i5 G-WIN Full IP67 Panel PC | Winmate")
-F-L4-O-202011171114360.png "R15IK3S-67C3(HB) | 15\" Intel® Core™ i5 G-WIN Full IP67 Panel PC | Winmate")
An actual flat, easy-to-clean front surface with an edge-to-edge design
Winmate's Flat aluminum P-Cap panel PCs and display go beyond standard industrial panel computers with an elegant, edge-to-edge design. Easy to maintain and clean to prevent water or liquid droplets penetrates every opening in the device.
Full IP67 Protection against water and dust with M12 Connectors
Winmate multipurpose and waterproof fully sealed IP67 panel pc is protected against outer dust and water splash, and ideal for harsh environments.
Fanless cooling system and ultra-low power consumption
G-WIN line offered fanless, low power platform design, sunlight readable panels, WLAN integration, anti-shock and vibration, and anti-corrosion coating with aluminum alloy housings. With the new generation of G-WIN, Winmate extends the line once again by offering a panel product with Intel's next-generation Bay Trail and Broadwell processor paired with genuine Intel graphics resulting in high performance with low power consumption.
Complete input range power supply
Since panel computers are not mobile systems to be carried around, they have no internal battery (other than a possible backup battery or uninterruptible power supply). Instead, the devices use DC power via conventional external AC adapters. Winmate's standard configurations use 12 Volt DC with lockable power connectors. For applications that require a wide/variable input power range, Winmate offers a 9 to 36 Volt (for Intel Bay Trail-based panels) and 9 to 24 Volt (for NXP models) wide-range power option.
Anti-shock and vibration
Winmate did configure the G-WIN panel to pass them-STD-810F 516.5 Procedure I andMIL-STD-810F 514.5 vibration test. The overall construction of the G-WIN panel is inherently rugged. The aluminum die-cast housing is rock-solid, and special anti-construction treatment means it'll hold up even in exposed settings. The surface treatment is a very resistive black powder coating. Optical bonding with anti-moisture treatment is standard, and there's a protective glass option available.
Processor
Intel® Core™ i5-7200U (3M Cache, up to 3.10 GHz) Intel® Core™ i5-7300U (3M Cache, up to 3.50 GHz)
Memory
1 x SO-DIMM, DDR4 2133 MHz, 4GB 8GB (Optional) 16GB (Optional)
Storage
1 x M.2 2242 SSD 64GB M.2 2242 SSD up to 512GB (Optional)
Ethernet controller
Intel® Ethernet Controller I211-AT + Intel® Ethernet Connection I219-LM
Security
TPM 2.0
Operating System
Windows 10 IoT Enterprise (Optional) Linux Ubuntu 18.04 (Optional)
WLAN
Support (Optional)
BT
Support (Optional)
Size
15 inches
Touch / Glass
Resistive Touch Screen Bonding With Panel Protection Glass Without touch function (Optional)
Optional function
High brightness Panel for sunlight readable (Optional)
Resolution
1024x768
Panel Brightness
300 nits
Contrast Ratio
2000:1
View Angles
88,88,88,88
Active Area
304.1x228.1 mm
Dimension
398 x 308 x 58 mm
Mounting
VESA Mount Yoke Mount
Enclosure
Aluminum Housing
Cooling System
Fanless design
Operating Humidity
10% to 90% (non-condensing)
Operating Temperature
-10~60°C
Storage Temperature
-30~70°C
Shock
Ignore MIL-STD-810G Method 516.6 (Optional)
Vibration
MIL-STD-810G Method 514.6
IP rating
IP67
Certification
CE, FCC
USB Port
1 x M12 waterproof connector for 2 x USB2.0
Serial Port
1 x M12 waterproof connector for RS232
LAN
1 x waterproof Giga LAN RJ45 connector
Indicator
1 x LED Indicator for power 1 x LED Indicator for storage
Power Input
1 x M12 waterproof connector for 9~36V DC
Button
1 x Power Button 1 x Reset Button 1 x Lock / Unlock front key function button 1 x Auto Dimming / Manually button 1 x Day / Night Mode button 1 x Brightness Up button 1 x Brightness Down button 1 x LED indicator brightness adjustment button 1 x Light sensor
Accessory
External open wire Power cable with waterproof connector External USB cable with waterproof connector External COM cable with waterproof connector External LAN cable with waterproof connector Waterproof caps RJ45 female-female converter Driver CD & Manual VESA screws
Optional Accessory
Yoke mount stand (Optional) 100~240V AC to DC Adapter with power cord (Optional)
