R19IB3S-65M119" Intel® Celeron® N2930 IP65 Stainless Resistive Chassis Panel PC
- Intel® Celeron® Bay Trail-M N2930 1.83GHz Processor
- Fanless Design
- Full IP65 dust/water resistant
- SUS 316/ AISI 316 stainless steel for food and chemical industries
- Optical Bonding with Anti-moisture Treatment (Optional)
- 5 Wire Resistive Touch/ Anti-Reflection Protection Glass (Optional)
19" Intel® Celeron® N2930 IP65 Stainless Resistive Chassis Panel PC
The protection against water Panel PC complies with IP65 water and dust resistance for normal cleanup processes and strict hygiene standards in the Food, Beverage, and Pharmaceutical industries.
Comprehensive I/O Ports
Combining ruggedness with a range of I/O ports makes this device highly usable for multiple industrial applications. Plus, the waterproof connectors come with screw-on caps for added protection.
Projected Capacitive Multi-Touch (P-CAP)
The highly-sensitive touch screen and PCAP multi-touch support make it easy for users to key in data, rotate images, drag and drop files, and zoom in with two or more fingers.
Fully Sealed Connector and Cable Protection
Fully Sealed Connector protection means these displays are highly resistant to dust and water, which can be installed in the harshest industrial environments.
Touch / Glass
Resistive Touch Screen Protection Glass Without Touch Function (Optional)
Intel® Celeron® N2930 (2M Cache, up to 2.16 GHz)
1 x SO-DIMM, DDR3L 1600 MHz, 4GB 8GB (Optional)
1 x mSATA SSD 64GB. mSATA SSD up to 512GB. (Optional)
2 x Intel® Ethernet Controller I210-AT
Windows 7 Embedded Systems (Optional) Windows 10 IoT Enterprise (Optional) Linux Ubuntu 18.04 (Optional)
468 x 395 x 63 mm
VESA Mount Yoke Mount
10% to 90% (non-condensing)
1x M12 waterproof connector for 2 x USB2.0
1 x M12 waterproof connector for RS232
1 x waterproof Giga LAN RJ45 connector
1 x LED Indicator for power 1 x LED Indicator for storage
1 x M12 waterproof connector for 12V DC
1 x Power Button 1 x Reset Button
100~240V AC to DC Adapter with waterproof connector Power Cord External USB cable with waterproof connector External COM cable with waterproof connector External LAN cable with waterproof connector Waterproof caps Driver CD & Manual VESA screws
12V DC (M12 type)
