R19L300-PMA3OD 19" Resistive Touch Panel Mount Display
KEY FEATURES
- Sunlight readable with high brightness solution
- Support panel mount
- Operating temperature:-10~60℃
- Optional operating temperature : -25~60℃ with heater solution
- Support resistive touch
- Optional solar radiation protection with UV film for directed sunlight environment
- CERTIFICATIONS
-
Easy Mounting
Winmate industrial outdoor display series support universal wall and flat surface mounting options. Enable easy installation and use in various industries according to your specific requirements.
Clear and Vibrant Displays
Winmate outdoor display product family boosts sunlight-readable and high brightness solutions to enhance users’ readability even under direct sunlight in outdoor environments and support 24/7 visual operation.
Built for Outdoor Use
With the optional heater, Winmate outdoor displays support a wide range of temperatures. Also, the optional UV Film for added solar radiation protection on the panel makes the touchscreen suitable for various industrial and commercial applications.
Size
19.0 inches
Touch / Glass
Resistive Touch Screen Protection Glass w/o Touch Function (Optional)
Resolution
1280x1024
Panel Brightness
1000.0 nits
Contrast Ratio
1000:1
View Angles
85,85,80,80
Display Color
16.7M Colors
Active Area
376.32x301.06 mm
Operating Humidity
10% to 90% RH, Non-Condensing
Operating Temperature
-10°C to 60°C
Storage Temperature
-20°C to 70°C
Certification
CE, FCC
USB Port
1 x USB for Touch Screen
Video
1 x VGA 1 x HDMI (Optional) 1 x DVI (Optional)
Audio
Audio line in (3.5mm) (Optional) 2 x Speaker (Optional)
Dimension
474 x 384 x 63 mm
Cut out
446 x 356mm
Mounting
VESA Mount/ Panel Mount
Enclosure
Metal Housing with Aluminum Bezel
Cooling System
Fanless Design
Accessory
1 x VGA cable 1 x HDMI cable 100~240V AC to DC Adapter Power Cord Manual VESA screws(Varies by product)
Optional Accessory
Remote Controller (Optional,Varies by product)
Power Rating
12V DC in 24V DC in (optional)
Button
5 Keys: - , + , Power , Esc , Enter
