R20L100-RKA2ML 20.1" Rack Mount Protective Glass Defence Display
The R20L100-RKA2ML has been phased out and replaced by the R21L100-MLM1FP. For more information, please get in touch with us.
- Compliant MIL-STD 810G/ MIL-STD 461E Rack Mount Protective Glass Defence Display
- Rack mount mechanical design, supports VESA mount
- High image quality, 1600 x 1200 pixels resolution
- AR protection glass
- Defence-grade power connector (MIL-DTL-38999/1)
- AC 100~240V, Universal, ±10%; DC 9~36V, ±10% (Optional)
- Resistive Touch (Optional)
- Build-in Light Sensor for Auto Brightness Control
Reliable Computing Tailored for Defence Applications
To meet the regulatory requirements of the Defence and defense, all Winmate's Defence Console Rack Displays are built and tested according to MIL-STD-810G environmental and MIL-STD 461F EMC standard. Winmate performs in-house reliability test to ensure optimal performance in harsh defence environments.
Command Center Focused Design
Increase the efficiency of the command center and control room personnel. Built your ergonomic command console that complies with Defence and defense precise needs with Defence Console Rack Displays that feature rack mount mechanical design (8U).
Defence – Grade Connectors for Compatibility with Existing Defence Systems
The Defence Console Rack Displays come with MIL-DTL-38999 type I power input connector – high-performance cylindrical connector for cable-to-panel applications in the defence, air traffic control, or other mission-critical situations. Compatible with existing defence systems.
Ultimate Touch Experience and Convenient On-Screen User Controls
The Defence Console Rack Displays feature a user-friendly touchscreen and physical OSD buttons for fast access to the central control located on the front panel.
Auto Brightness Control with Built-in Light Sensor
The Defence Console Rack Displays feature a built-in light sensor for auto-brightness control. The screen brightness effortlessly changes with the lighting conditions throughout the day.
Touch / Glass
10% to 95% RH
RE101 / RE102 CE101 / CE102 with EMI Glass / Touch(Optional) RS101 / RS 103 CS101 / CS 106 / CS 109 / CS 114 / CS 115 / CS 116
Vibartion Method 514.5 Humidity Method 507.4 Transit Drop Method516.5
1 x 15 Pin D-Sub 5 x BNC 1 x DVI-D
482.6 x 399.3 x 80 mm
Rack Mount/ VESA Mount
Metal Housing with Aluminum Bezel
AC 100~240V, Universal, ±10% DC 9~36V, ±10% (Optional)
1 x User Manual(Hardcopy) 1 x Power Cord MIL-DTL-38999/1 1 x VGA Cable 1 x DVI Cable 1 x VGA to 5 BNC Shielding Cable
8 key: Power Menu Auto Volume Up/ Swap Volume Down/ PIP Brightness Up Brightness Down LED Adjustment
