W24L100-MLA2FP 23.8" PCAP Rack Mount Defence Display
- 23.8", 1920 x 1080 resolution
- Compliant MIL-STD 810G/ MIL-STD 461E
- Rack mount mechanical design, supports VESA mount
- PCAP multi-touch screen
- Military-grade power connector (MIL-DTL-38999/1)
- AC 100~240V, Universal, ±10%; DC 9~36V, ±10% (Optional)
- Convenient on-screen display controls
23.8" PCAP Rack Mount Defence Display
Reliable Computing Tailored for Defence Applications
To meet the regulatory requirements of the military and defense, all Winmate's Defence Console Rack Displays are built and tested according to MIL-STD-810G environmental and MIL-STD 461F EMC standard. Winmate performs in-house reliability test to ensure optimal performance in harsh defence environments.
Command Center Focused Design
Increase the efficiency of the command center and control room personnel. Built your ergonomic command console that complies with military and defense precise needs with Defence Console Rack Displays that feature rack mount mechanical design (8U).
Defence – Grade Connectors for Compatibility with Existing Defence Systems
The Defence Console Rack Displays come with MIL-DTL-38999 type I power input connector and, for selected models, MIL-DTL-38999 type III input/ output connectors – high-performance cylindrical connector for cable-to-panel applications in the defence, air traffic control, or other mission-critical situations. Compatible with existing defence systems.
Projected Capacitive touchscreen technology (PCAP) Experience
Using Projected Capacitive touchscreen technology (PCAP) allows for a modern user interface thereby making use of new and extended ways of user input and control. Gesture-based interactions by touching and pointing, with one finger or more, rotate, pinch to zoom and move objects on the display.
Auto Brightness Control with Built-in Light Sensor
The Defence Console Rack Displays feature a built-in light sensor for auto-brightness control. The screen brightness effortlessly changes with the lighting conditions throughout the day.
Touch / Glass
Projected Capacitive Multi Touch Screen PCAP with With ITO Flim (Optional)
10% to 95% RH
RE101 / RE102 CE101 / CE102 with EMI Glass / Touch(Optional) RS101 / RS 103 CS101 / CS 106 / CS 109 / CS 114 / CS 115 / CS 116
Vibartion Method 514.5 Humidity Method 507.4 Transit Drop Method516.5
1 x USB for Touch
1 x VGA 5 x BNC (R,G,B,H,V) 1 x DVI-D
635.2 x 430.9 x 66 mm
Rack Mount/ VESA Mount
Metal Housing with Aluminum Bezel
1 x User Manual(Hardcopy) 1 x Power Cord MIL-DTL-38999/1 1 x VGA Cable 1 x DVI Cable 1 x VGA to 5 BNC Shielding Cable
AC 100~240V, Universal, ±10% DC 9~36V, ±10% (Optional)
7 key: Power Decrease Increase Exit/ Auto Menu Day/ Night Lock/ Unlock
