W32IW3S-MLA3FP32" Intel® Core™ i5-8265U Defence Console Rack Panel PC

KEY FEATURES

  • Intel® Core™ i5-8265U 1.6GHz Processor
  • Anti-Corrosion Housing / Fanless
  • Projective Touch
  • Compliant with MIL-STD-810G/F , MIL-STD-461E/F
  • Flush Rack / Rack Mount Mechanical Design (8U)
  • Convenient On-Screen Display Controls
  • AC 110~240 V Power input default
  • Isolation DC 9~36 V Power input (Optional)
  • Built-in Light Sensor for auto brightness control
  • CERTIFICATIONS
  • MIL-­STD 461F MIL-STD 810G FCC CE

W32IW3S-MLA3FP

32" Intel® Core™ i5-8265U Defence Console Rack Panel PC
Overview
Specification
Reliable Computing Tailored for Defence Applications

Reliable Computing Tailored for Defence Applications

To meet the defence and defense regulatory requirements, all Winmate's Defence Console Rack Panel PCs are built and tested according to MIL-STD-810G environmental and MIL-STD 461F EMC standard. Selected models support the NVIS MIL-STD-3009 night vision. Winmate performs in-house reliability test to ensure optimal performance in harsh defence environments.


Command Center Focused Design

Command Center Focused Design

Increase the efficiency of the command center and control room personnel. Built your ergonomic command console that complies with defence and defense precise needs with Defence Console Rack Panel PCs that feature rack mount mechanical design (8U).


Defence–Grade Connectors for Compatibility with Existing Defence Systems

Defence – Grade Connectors for Compatibility with Existing Defence Systems

The Defence Console Rack Panel PCs come with a MIL-DTL-38999 type I power input connector. For selected models, MIL-DTL-38999 type III input/ output connectors – high-performance cylindrical connector for cable-to-panel applications in the defence, air traffic control, or other mission-critical situations. Compatible with existing defence systems.


Survives All Weather Conditions

Ultimate Touch Experience and Convenient On-Screen User Controls

The Defence Console Rack Panel PCs feature a user-friendly touchscreen and physical OSD buttons for fast access to the central control located on the front panel.


Auto Brightness Control with Built-in Light Sensor

Auto Brightness Control with Built-in Light Sensor

The Defence Console Rack Panel PCs feature a built-in light sensor for auto-brightness control. The screen brightness effortlessly changes with the lighting conditions throughout the day.

Display

Size

32 inches

Touch / Glass

Projected Capacitive Multi Touch Screen

Resolution

1920x1080

Panel Brightness

400 nits

Contrast Ratio

4000:1

View Angles

89,89,89,89

Active Area

698.4 x 392.85 mm

System Specification

Processor

Intel® Core™ i5 -8265U (6M Cache, 1.6GHz up to 3.9 GHz)

Memory

1 x SO-DIMM, DDR4 2400 MHz, 4GB 8GB (Optional) 16GB (Optional) 32GB (Optional)

Storage

1 x M.2 2242 B-key SSD 64GB up to 512GB (Optional)

Ethernet controller

Intel® Ethernet Controller I210-AT + Intel® Ethernet Connection I219-LM

Operating System

Windows 10 IoT Enterprise (Optional)

Environment

Operating Humidity

10% to 95% RH

Operating Temperature

0~50°C

Storage Temperature

-10°C~60°C

Compliance

MIL-STD 461E/F

RE101 / RE102 CE101 / CE102 with EMI Glass / Touch(Optional) RS101 / RS 103 CS101 / CS 106 / CS 109 / CS 114 / CS 115 / CS 116

MIL-STD 810F/G

Vibartion Method 514.5 Humidity Method 507.4 Transit Drop Method516.5

Certification

Certification

CE, FCC

IO Ports

USB Port

2 x USB 3.2 Gen 1

Serial Port

1 x RS232/422/485 (Default RS232)

LAN

2 x RJ-45

Video

1 x HDMI (Optional)

Mechanical

Dimension

825 x 500 x 87.2 mm

Mounting

VESA Mount/ Rack Mount

Enclosure

Metal Housing with Aluminum Bezel

Cooling System

Fanless Design

Accessory

Accessory

1 x Manual(Hardcopy) 1 x Driver CD 1 x Power Cord (MIL-DTL-38999/1)

Power

Power Rating

AC 100~240V, Universal, ±10% DC 9~36V, ±10% (Optional)

Control

Button

8 Key OSD Control Pad: Power, Brightness DOWN, Brightness UP, Night, Day, Auto / Manual, Reset, Lock
