W32L100-PTA3-ME32" Multi Touch Color Surgical Display

KEY FEATURES

  • 32” 1920 x 1080 with P-CAP touchscreen, Multi-Touch Color Surgical Display
  • Bottom side keys x 5
  • Fanless and Ventless design, Easy-to-Clean medical grade monitors
  • Support VGA, HDMI signal input
  • Front IP65
  • CERTIFICATIONS
  • FCC CE

W32L100-PTA3-ME

32" Multi Touch Color Surgical Display
Overview
Specification
Easy-to-clean Surface

Easy-to-clean Surface

The flat surface simplifies the disinfection process. Cleaning liquids can be used on the screen to maximize safety and hygiene. Plus, white-colored housing makes it easy for users to detect and remove dust or other foreign substances.


Perfect Medical Images Reproduction

Perfect Medical Image Reproduction

The high-resolution LCD screen with wide-viewing angles offers sharp and bright images to deliver spectacular contrast and colors for surgical operations, diagnosis, and clinical review applications.


Ergonomic Design and Easy Installation

Ergonomic Design and Easy Installation

The display features a sleek, lightweight design that is compatible with VESA mounting options. The low-cost installation of these displays can be used in a broad range of applications. The display can be installed vertically or horizontally to suit any environment.


Intuitive User Controls

Intuitive User Controls

The PCAP multi-touch technology allows the use of multiple fingers at the same time. Take full advantage of the multi-touch screen and scroll, tap, zoom in or zoom out of medical images for precise diagnostics and better prevention measures.

Display

Size

32.0 inches

Touch / Glass

Projected Capacitive Multi Touch Screen

Resolution

1920x1080

Panel Brightness

400 nits

Contrast Ratio

4000:1

View Angles

89,89,89,89

Display Color

16.7M Colors

Active Area

698.4 x 392.85 mm

Environment

Operating Humidity

10% to 90% RH, non-condensing

Operating Temperature

0°C to 35°C

Storage Temperature

-20 °C to 60 °C

Certification

Certification

CE, FCC

Compliance

Compliance

IEC 60601-1:2005 + A1:2012 (Ed. 3.1) IEC 60601-1-6:2010 + A1:2013 (Ed. 3.1) IEC 62366:2007 + A1:2014 (Ed. 1.1) ANSI/AAMI ES60601-1:2005/A1:2012 and C1:2009/(R)2012 and A2:2010/(R)2012 CAN/CSA-C22.2 No.60601-1:14 EN 60601-1-2:2015, IEC 60601-1-2:2014 (Ed. 4.0) EN 55032/EN 55024, FCC part 15B EN 62368-1:2014 RoHS-2, REACH, WEEE compliant

IO Ports

USB Port

1 x USB for Touch Screen

Video

1 x VGA 1 x HDMI

Audio

2 x Speaker

Mechanical

Dimension

799 x 478 x 63.7 mm

Mounting

VESA Mount

Enclosure

Plastic

Cooling System

Fanless Design

Accessory

Accessory

1 x VGA cable 1 x HDMI cable 100~240V AC to DC Adapter Power Cord Manual VESA screws Remote Controller

Optional Accessory

USB cable for Touch (Optional)

Power

Power Rating

12V DC input

Control

Button

5 Keys: - , + , Power , Esc , Enter
