R15IW3S-MLA3FP

15" Intel® Core™ i5-8265U Defence Console Rack Panel PC

KEY FEATURES

Intel® Core™ i5-8265U 1.6GHz Processor
Anti-Corrosion Housing / Fanless
Projective Touch
Compliant with MIL-STD-810G/F , MIL-STD-461E/F
Flush Rack / Rack Mount Mechanical Design (8U)
Convenient On-Screen Display Controls
AC 110~240 V Power input default
Isolation DC 9~36 V Power input (Optional)
Built-in Light Sensor for auto brightness control

CERTIFICATIONS

DATASHEET RESOURCE

ADD TO INQUIRY

ADD TO COMPARE

R15IW3S-MLA3FP

15" Intel® Core™ i5-8265U Defence Console Rack Panel PC

Overview

Specification

Winmate 15-inch Defence Console Rack Panel PC features Reliable Imaging Solutions for Defence Applications

Reliable Computing Tailored for Defence Applications

To meet the defence and defense regulatory requirements, all Winmate's Defence Console Rack Panel PCs are built and tested according to MIL-STD-810G environmental and MIL-STD 461F EMC standards. Winmate performs in-house reliability tests to ensure optimal performance in harsh defence environments.

Ergonomic command console Design for Winmate 15-inch Defence Console Rack Panel PC

Command Center Focused Design

Increase the efficiency of the command center and control room personnel. Built your ergonomic command console that complies with defence and defense precise needs with Defence Console Rack Panel PCs that feature rack mount mechanical design (8U).

Winmate 15-inch Defence Console Rack Panel PC can be used for nearly any purpose

Defence – Grade Connectors for Compatibility with Existing Defence Systems

The Defence Console Rack Panel PCs come with a MIL-DTL-38999 type I power input connector. For selected models, MIL-DTL-38999 type III input/ output connectors – high-performance cylindrical connector for cable-to-panel applications in the defence, air traffic control, or other mission-critical situations. Compatible with existing defence systems.

Ultimate Touch Experience and Convenient On-Screen User Controls

The Defence Console Rack Panel PCs feature a user-friendly touchscreen and physical OSD buttons for fast access to the central control located on the front panel.

Winmate 15-inch Defence Console Rack Panel PC with Brilliant Screen

Auto Brightness Control with Built-in Light Sensor

The Defence Console Rack Panel PCs feature a built-in light sensor for auto-brightness control. The screen brightness effortlessly changes with the lighting conditions throughout the day.

Display

Size

15.0 inches

Touch / Glass

Projected Capacitive Multi Touch Screen (Default)
PCAP with With ITO Flim (Optional)

Resolution

1024x768

Panel Brightness

500.0 nits

Contrast Ratio

2500:1

View Angles

88,88,88,88

Active Area

304.1x228.1 mm

System Specification

Processor

Intel Core i5-8265U 1.6GHz (up to 3.9GHz)

Memory

1 x SO-DIMM, DDR4 2400 MHz, 4GB (Default)
8GB (Optional)
16GB (Optional)
32GB (Optional)

Storage

1 x M.2 2242 B-key SSD 64GB (Default)
up to 512GB (Optional)

Ethernet controller

Intel® Ethernet Controller I210-AT +
Intel® Ethernet Connection I219-LM

Operating System

Windows 10 IoT Enterprise (Optional)

Environment

Operating Humidity

10% to 95% RH

Operating Temperature

-20°C~60°C

Storage Temperature

-30°C~70°C

Compliance

MIL-STD 461E/F/G

RE101 / RE102
CE101 / CE102
CS118
with EMI Glass / Touch(Optional)
RS101 / RS 103
CS101 / CS 106 / CS 109 / CS 114 / CS 115 / CS 116

MIL-STD 810G/H

Vibration Method 514.6
Humidity Method 507.5
Transit Drop Method516.6

Certification

CE, FCC

Accessory

1 x Manual(Hardcopy)
1 x Driver CD
1 x Power Cord (MIL-DTL-38999/1)

Mechanical

Dimension

402 x 321 x 70 mm

Mounting

Rack Mount/ VESA Mount

Enclosure

Metal Housing with Aluminum Bezel

Cooling System

Fanless Design

IO Ports

USB Port

2 x USB 3.2 Gen 1

Serial Port

1 x RS232(Default)/422/485

LAN

2 x RJ-45

Video

1 x HDMI (Optional)

Power

Power Rating

AC 100~240V, Universal, ±10% (Default)
DC 9~36V, ±10% (Optional)

Control

Button

8 Key OSD Control Pad:
Power, Brightness DOWN, Brightness UP,
Night, Day, Auto / Manual, Reset, Lock

Winmate's 15" Intel® Core™ i5-8265U Defence Console Rack Panel PC is a powerful and reliable solution for a wide range of industrial and military applications. With its durable design and range of advanced features, this panel PC is suitable for use in even the most challenging environments. One key feature of this panel PC is its powerful Intel® Core™ i5-8265U processor. With a clock speed of up to 3.9GHz, this processor delivers excellent performance for demanding applications. Whether it's for controlling industrial machinery or running military operations, this panel PC can handle the most demanding tasks with ease. Another key feature of this Defence Console Rack Panel PC is its Projective Touch display. This technology allows for accurate and responsive touch input, making it easy for operators to interact with the device. Additionally, the panel PC comes with convenient on-screen display controls that allow operators to quickly adjust various settings such as brightness, contrast, and volume. One unique feature of this panel PC is the built-in light sensor for auto brightness control. This feature ensures that the display maintains optimal brightness levels, regardless of ambient light conditions. This is especially useful in environments where lighting conditions may vary, as it ensures that critical information is always visible and easy to read. In addition to these features, this Defence Console Rack Panel PC is also built to withstand the rigors of harsh environments. Its durable construction ensures that it can withstand exposure to dust, moisture, and other environmental factors that could damage less rugged devices. Overall, Winmate's 15" Intel® Core™ i5-8265U Defence Console Rack Panel PC is a reliable and powerful solution for a wide range of industrial and military applications. Its Projective Touch display, convenient on-screen display controls, and built-in light sensor make it easy to use and maintain, while its rugged construction ensures that it can withstand the most challenging environments. Whether it's for controlling machinery or managing military operations, this panel PC is a versatile and dependable choice.
