IBDRW100-EX
ATEX DIN Rail PC (C1D2 Certified) with Intel® Celeron® N2930
Key Features
- Class 1, Division 2 & ATEX Zone 2 device certified for hazardous area application
- Designed for industrial automation, DIN Rail application
- Intel® Celeron® N2930 Bay Trail-M Processor
- 1 x RS232 / 422 / 485 communication, switch by jump
- 4 x Giga LAN, 1 x USB 3.0, 3 x USB 2.0, 1 x VGA, 1 x Line out, 1 x Power Jack
- Fanless, streamlined enclosure for highly efficient heat dissipation
- Rated for wide temperature use -20˚C to 60˚C
- AWS loT Greengrass Certified
Introduction
Winmate DIN Rail ATEX Box PC Series is a robust and reliable computing solution designed for hazardous industrial environments. Certified for Class 1, Division 2, and ATEX Zone 2, it ensures safe operation in hazardous areas while delivering high performance with Intel processors. Built with a fanless design for efficient heat dissipation, it withstands wide temperature ranges and challenging conditions. Ideal for industrial automation, remote data collection, and process control, this rugged box PC is a versatile choice for demanding applications.
Specifications
System Specification
Processor
Intel Celeron N2930 1.83GHz (up to 2.16GHz)
Memory
1 x SO-DIMM, DDR3L 1600 MHz, 4GB (Default)
8GB (Optional)
8GB (Optional)
Storage
1 x mSATA SSD 128GB (Default)
256GB (Optional)
512GB (Optional)
1 x SATA III for 2.5" SSD/HDD (Optional)
256GB (Optional)
512GB (Optional)
1 x SATA III for 2.5" SSD/HDD (Optional)
Ethernet controller
4 x Intel® Ethernet Controller
Security
TPM (Optional)
Operating System
Windows 7 Embedded Systems (Optional)
Windows 10 IoT Enterprise (64 bit) (Optional)
Linux Ubuntu 20.04 (Optional)
Windows 10 IoT Enterprise (64 bit) (Optional)
Linux Ubuntu 20.04 (Optional)
WLAN
Support (Optional)
BT
Support (Optional)
Expansion Port
1 x mPCIe slot(for Wi-Fi)
1 x mPCIe slot(for SSD)
1 x mPCIe slot(for SSD)
Mechanical
Dimension
139 x 65.4 x 152 mm
Weight
1.5 kg
Mounting
Din-Rail mounting
Enclosure
Aluminum Housing
Cooling System
Fanless Design
Environment
Operating Humidity
10% to 90% RH, Non-Condensing
Operating Temperature
-20°C to 60°C
Storage Temperature
-40°C to 80°C
Shock
(Default)
MIL-STD-810G Method 516.6 Procedure I (Optional)
MIL-STD-810G Method 516.6 Procedure I (Optional)
Vibration
MIL-STD-810G Method 514.6 Procedure I
Certification
Certification
CE, FCC
UL 508
CSA C22.2 No.142-m1987
UL 60950-1
CSA C22.2 No. 60950-1-07
EN 62368-1
Class I, Div.2, Groups A,B,C,D
-20 <= Tamb <= 60
Meet Standards
ANSI/ISA-12.12.01-2013-6-03
CAN/CSA C22.2 No. 213-M1987
ATEX II 3G Ex nA IIC T4 Gc
-20 <= Tamb <= 60
Meet Standards
EN 60079-0, EN 60079-15
UL 508
CSA C22.2 No.142-m1987
UL 60950-1
CSA C22.2 No. 60950-1-07
EN 62368-1
Class I, Div.2, Groups A,B,C,D
-20 <= Tamb <= 60
Meet Standards
ANSI/ISA-12.12.01-2013-6-03
CAN/CSA C22.2 No. 213-M1987
ATEX II 3G Ex nA IIC T4 Gc
-20 <= Tamb <= 60
Meet Standards
EN 60079-0, EN 60079-15
IO Ports
Power Input
1 x Isolated 9~36V DC with 3-Pin Terminal Block
USB Port
1 x USB3.2 Gen1x1 (Type-A)
3 x USB2.0 (Type-A)
3 x USB2.0 (Type-A)
Serial Port
1 x RS232/422/485 DB9 connector (Default RS232)
1 x Isolated RS422/485 DB9 connector (Default RS422)
1 x Isolated RS422/485 DB9 connector (Default RS422)
Video
1 x VGA DB15 connector
Audio
Mic in
Line in
Line out
Line in
Line out
Expansion Port
1 x mPCIe slot(for SSD)
1 x mPCIe slot(for Wi-Fi module)
1 x mPCIe slot(for Wi-Fi module)
LAN
4 x Giga LAN RJ45 Connector
(one of them is disabled if WLAN module is added)
(one of them is disabled if WLAN module is added)
Indicator
1 x LED Indicator for power
1 x LED Indicator for storage
1 x LED Indicator for storage
DIDO
1 x Isolated 5V 9-in/9-out DIO with 20-Pin Terminal block (Default)
1 x Isolated 30V 9-in/8-out DIO with 20-Pin Terminal block (Optional)
1 x Isolated 30V 10-in/7-out DIO with 20-Pin Terminal block (Optional)
1 x Isolated 30V 11-in/6-out DIO with 20-Pin Terminal block (Optional)
1 x Isolated 30V 12-in/5-out DIO with 20-Pin Terminal block (Optional)
1 x Isolated 30V 9-in/8-out DIO with 20-Pin Terminal block (Optional)
1 x Isolated 30V 10-in/7-out DIO with 20-Pin Terminal block (Optional)
1 x Isolated 30V 11-in/6-out DIO with 20-Pin Terminal block (Optional)
1 x Isolated 30V 12-in/5-out DIO with 20-Pin Terminal block (Optional)
Control
Button
1 x Reset Button
Accessory
Accessory
1 x 100~240V AC to DC Adapter
1 x Power Cord
2 x Terminal Block 10 pin fconnector for DIDO
1 x Open Wire Cable
1 x Terminal Block 3 pin to 2.5Ø Female Adapter Cable
1 x Din Rail Mounting kits
1 x Cable Holder kits
1 x Power Cord
2 x Terminal Block 10 pin fconnector for DIDO
1 x Open Wire Cable
1 x Terminal Block 3 pin to 2.5Ø Female Adapter Cable
1 x Din Rail Mounting kits
1 x Cable Holder kits
Power
Power Rating
9V to 36V DC with isolation, 3-Pin Terminal Block
Adapter
12V 36W
Dimensions Unit:mm
Note
1. Total usable memory will be less dependent upon actual system configuration.2. LAN3 disabled if WLAN Module is added.
3. Length measurements do not include protrusions. Weight varies with options.
4. Measured at maximum backlight and high CPU load.
5. Accessories and integrated options may vary depending on your configuration
6. This is a simplified drawing and some components are not marked in detail.
7. All specifications are subject to change without prior notice.
8. The product shown in this datasheet is a standard model. For diagrams that contain customized or optional I/O, please contact the Winmate Sales Team for more information.
