R12L600-MRM2
12.1" Marine Display
Key Features
- 12.1" 1024 x 768 resolution
- Resistive touch screen (Optional protection glass w/o touch function)
- IP66 aluminum housing with powder coating design (IP54 rear)
- 9 to 36 V DC power supply with terminal block (Default)
- Picture-in-picture (PIP) function and multi-video inputs
- Ease-of-use front panel OSD control
- Enhanced shock and vibration resistance
- Dimming knob to control backlight brightness from nearly 0% to 100%
Introduction
Winmate Marine Display Series provides reliable and durable performance for maritime environments, available in sizes from 10.1" to 24". Certified with DNVGL-CG-0339, IEC60945 4th, and IACS E10 standards, these displays ensure compliance with marine industry requirements. Featuring an IP66 aluminum housing with powder coating (IP54 rear), a dimming knob for precise backlight control, and enhanced shock and vibration resistance, they are built for harsh conditions. With optional touchscreen or AR protection glass, multi-video inputs, and user-friendly front panel OSD controls, these displays are ideal for navigation and control applications.
Specifications
Display
Resolution
1024x768
Size
12.1 inches
Contrast Ratio
1000:1
Panel Brightness
500.0 nits
Display Color
16.2M Colors
View Angles
89,89,89,89
Active Area
245.76x184.32 mm
Touch / Glass
Resistive Touch Screen (Default)
AR Glass (Optional)
AR Glass (Optional)
Environment
Operating Humidity
5% to 95%
Operating Temperature
-15~55°C
Shock
15G,11ms duration
Vibration
0.7g@DNV-CG-0339 (Class A)
IP rating
IP66 (Front Side)
Certification
Certification
CE, FCC
IO Ports
Serial Port
1 x RS232 for Remote Control
1 x RS232/USB for Touch Screen
1 x RS232/USB for Touch Screen
Video
1 x VGA
1 x DVI-D
1 x Composite
1 x S-Video
1 x DVI-D
1 x Composite
1 x S-Video
Mechanical
Dimension
337 x 293.2 x 70.8 mm
Weight
4kg
Mounting
VESA mount/Panel mount
Enclosure
Metal Housing with Aluminum Bezel
Cooling System
Fanless Design
Cut out
307 x 253mm
Power
Power Rating
9~36V DC Input Acceptable
Consumption
35W (Typical)
Accessory
Accessory
1 x User Manual.
1 x DVI Cable.
1 x VGA Cable.
1 x RS232 Serial Cable.
1 x S-Video Cable.
1 x Composite Cable.
1 x DVI Cable.
1 x VGA Cable.
1 x RS232 Serial Cable.
1 x S-Video Cable.
1 x Composite Cable.
Control
Button
8 key:
Esc/PIP
Auto adjustment
Left
Right/Source
OK/Menu
Up
Down
Power
1 x The Dimming Knob
Esc/PIP
Auto adjustment
Left
Right/Source
OK/Menu
Up
Down
Power
1 x The Dimming Knob
Dimensions Unit:mm
Note
1. This is a simplified drawing and some components are not marked in detail.2. Please contact our sales representative if you need further product information.
3. All specifications are subject to change without prior notice.
4. The product shown in this datasheet is a standard model. For diagrams that contain customized or optional I/O, please contact the Winmate Sales Team for more information.
