R15IK3S-GCC3(HB)
15" Intel® Core™ i5-7200U Standalone Panel PC HMI
-45-L4-I.png)
Key Features
- 15” 1024 x 768 with P-CAP touchscreen
- High computing performance with 7th Generation(kaby Lake) Intel® Core™ i5-7200U processor
- Fanless cooling system and ultra-low power consumption
- Front IP65 for protection against water and dust
- A true flat, easy-to-clean front surface with edge-to-edge design
- Plenty of I/O, including 2 x LAN, 1 x COM, 2 x USB 3.0, 1 x HDMI
Introduction
Winmate R15IK3S-GCC3(HB) is a 15-inch Intel® Core™ i5-7200U Standalone Panel PC HMI engineered for machine control, factory automation, and operator HMI. It combines Intel® Core™ i5-7200U, 15-inch display with 1024x768 resolution, and IP65 to support reliable operation in harsh industrial environments. With Android, the R15IK3S-GCC3(HB) helps OEMs, system integrators, and project teams deploy durable, configurable solutions for demanding field, factory, and mission-critical applications.
Specifications
Display
Touch / Glass
Projected Capacitive Multi Touch Screen (Default)
Anti-glare Coating (Optional)
Anti-glare Coating (Optional)
Resolution
1024x768
Size
15 inches inches
Contrast Ratio
2000:1
Panel Brightness
300 nits (Default)
1000 nits(Optional)
1000 nits(Optional)
View Angles
88,88,88,88
Active Area
304.1x228.1 mm mm
System Specification
Processor
Intel® Core™ i5-7200U (3M Cache, up to 3.10 GHz, BGA onboard CPU)
Intel® Core™ i5-7300U (3M Cache, up to 3.50 GHz, BGA onboard CPU)
Intel® Core™ i5-7300U (3M Cache, up to 3.50 GHz, BGA onboard CPU)
Memory
1 x SO-DIMM, DDR4 2133 MHz, 4GB (Default)
8GB (Optional)
16GB (Optional)
8GB (Optional)
16GB (Optional)
Storage
1 x M.2 2242 SSD 128GB (Default)
M.2 2242 SSD up to 512GB (Optional)
M.2 2242 SSD up to 512GB (Optional)
Ethernet controller
2 x Intel® Ethernet Controller
Security
TPM 2.0
Operating System
Windows 10 IoT Enterprise (Optional)
Linux Ubuntu 20.04 (Optional)
Linux Ubuntu 20.04 (Optional)
WLAN
Support (Optional)
BT
Support (Optional)
Sensors
Environment
Operating Humidity
10% to 90% (Non-Condensing)
Operating Temperature
0~50°C
Storage Temperature
-20~60°C
Shock
MIL-STD-810G Method 516.6
Vibration
MIL-STD-810G Method 514.6
IP rating
Front IP65
Certification
Certification
CE, FCC
IO Ports
Power Input
USB Port
2 x USB 3.0
Serial Port
1 x RS232/422/485 (Default RS232) (Default)
1 x RS232 (Optional)
1 x RS232 (Optional)
Video
1 x HDMI (Optional)
Audio
2 x Speaker
LAN
2 x RJ-45
Mechanical
Dimension
363.4 x 277.9 x 45.2 mm
Mounting
VESA Mount/ Panel Mount
Enclosure
Aluminum
Cooling System
Fanless Design
Accessory
Accessory
Quick Start Guide(Hardcopy)
Driver CD & User Manual
AC Adapter
Power Cable
Driver CD & User Manual
AC Adapter
Power Cable
Power
Power Rating
12V DC in (Default)
9-36V DC in (Optional)
9-36V DC in (Optional)
Control
Button
1 x Power Button
1 x Reset Button
1 x Reset Button
Dimensions Unit:mm
-01-L4-D1.svg)
Note
1. This is a simplified drawing and some components are not marked in detail.2. Please contact our sales representative if you need further product information.
3. All specifications are subject to change without prior notice.
4. The product shown in this datasheet is a standard model. For diagrams that contain customized or optional I/O, please contact the Winmate Sales Team for more information.
