R15L600-65EX 15" IP65 Stainless ATEX rugged touchscreen

KEY FEATURES

  • Class 1, Division 2 & ATEX Zone 2 application certification rugged touchscreen
  • 15” 1024 x 768, 550 nits (Optional 1000 nits) LCD Panel
  • Explosion-proof 5-wire resistive touch
  • Stainless steel design
  • IP65 Certified, dust-proof and water-resistant
  • Wide temperature range -20˚C to 50˚C
  • CERTIFICATIONS
  • CUL TS TD0700KL MIL-STD 810G IP65 ATEX & C1D2 FCC CE

R15L600-65EXNew Design

15" IP65 Stainless ATEX rugged touchscreen
Overview
Specification
Winmate IP65 Stainless ATEX rugged touchscreen certified for use in hazardous locations such as potential explosion area

Certified for Hazardous Locations

The R15L600-65EX is ATEX Zone 2 certified computers for remote data collection, process visualization, and control. Suitable for the deployment in ATEX Zone, where safety is the priority.


Take production control to the next level with real-time data monitoring and visualization on Winmate IP65 Stainless ATEX rugged touchscreen

Real-Time Production Monitoring and Control

Take production control to the next level with real-time data monitoring and visualization. The R15L600-65EX is a stainless ATEX display with a set of features designed to withstand industrial use in hazardous locations and extreme temperatures while providing high tech solutions that increase productivity, improve safety, and reduce operational costs.


Winmate IP65 Stainless ATEX rugged touchscreen with standarized VESA mount

Supports VESA Mount

The R15L600-65EX supports standardized VESA 100 x 100 mm mount for the simple installation of the chassis at the operation location, compatible with swing arm mounting kits. The R15L600-EX ATEX display also supports a rear mount for installation inside a panel or console.


Winmate explosion-proof IP65 Stainless ATEX rugged touchscreen

Explosion-Proof Resistive Touchscreen

The R15L600-65EX features explosion-proof ELO 5W resistive touch or ELO 5W projected capacitive PCAP multi-touch. Easy user controls and durability for some of the most demanding applications, such as control panel on a drilling rig.


Winmate IP65 Stainless ATEX rugged touchscreen designed to be rugged and durable

Rugged and Waterproof Design

The R15L600-65EX ATEX display offers full IP65 protection against dust and water, withstands vibration, and compliant with MIL-STD-810F standard requirements. Resists vibration that often occurs on the industrial site and in potentially explosive environments. All the I/O ports are feature waterproof connectors M12 type for maximum protection in wet and dusty operation conditions.

Display

Touch / Glass

Resistive Touch Screen Bonding With Panel (Explosion-Proof)

Size

15 inches

Resolution

1024x768

Panel Brightness

550 nits 1000 nits(Optional)

Contrast Ratio

2000:1

View Angles

88,88,88,88

Display Color

16.2M Colors

Active Area

304.1x228.1 mm

Mechanical

Dimension

396 x 310 x 49 mm

Mounting

VESA Mount

Enclosure

Stainless Housing

Cooling System

Fanless design

Environment

Operating Humidity

10% to 95% (non-condensing)

Operating Temperature

-20~50°C

Storage Temperature

-20~50°C

Shock

MIL-STD-810G Method 516.6 (Optional)

Vibration

MIL-STD-810G Method 514.6

Drop

MIL-STD-810G Method 516.6

IP rating

IP65

Certification

Certification

CE, FCC UL60950-1, CSA C22.2 No. 60950-1-07, EN 62368-1, IEC60950-1 ATEX Zone 2 EX II 3 G Ex ic nA IIC Gc UL Class I, Div.2, Groups ABCD T4 ANSI/ISA12.12.01 CAN/CSA C22.2 No. 213-M1987

IO Ports

USB Port

1x M12 type connector for Touchscreen

Serial Port

1 x M12 type connector for Touch 1 x M12 type connector for RS232 remote control (Optional)

Video

1x M12 type connector for VGA input

Indicator

1 x LED Indicator for power 1 x LED Indicator for standby

Power Input

1 x 9~36V DC, M12 Type connector

Control

Button

1 x Power Button 1 x Adjust up button 1 x Adjust down button 1 x ESC (Auto) button 1 x OK (Menu) button

Accessory

Accessory

100~240V AC to DC Power Adapter with M12 Connector Power Cord M12 Type Power Cable M12 Type RS232 Male Cable for remote control M12 Type USB Male Cable for Touch M12 Type VGA Cable Driver CD & Manual VESA screws

Optional Accessory

M12 Type RS232 Male Cable for touchscreen control (Optional)
