R15L100-RKA1
15" Rack Screen Mount

Winmate R15L100-RKA1 is a 15-inch Rack Screen Mount designed for industrial automation, embedded systems, and mission-critical applications. This product helps industrial buyers, OEMs, and system integrators select a reliable Winmate solution for rugged, embedded, or mission-critical environments where performance, durability, and long lifecycle availability matter. Best for: The R15L100-RKA1 is best suited for industrial automation, embedded systems, and mission-critical applications, especially when teams need stable hardware integration, dependable field operation, and a supplier with industrial computing experience. Key specifications: Important product highlights include 15", 1024 x 768, VGA and HDMI input, Rack screen mount, and VESA mount. SEO search intent: This content is optimized for users searching for R15L100-RKA1, Winmate R15L100-RKA1, Winmate industrial computer solution, industrial computer solution, 15-inch industrial computer solution, and industrial computer solution for industrial automation, and for purchase-intent queries related to industrial-grade Winmate hardware, rugged computing, embedded systems, and application-ready product solutions.

KEY FEATURES

  • 15", 1024 x 768
  • VGA and HDMI input
  • Rack screen mount
  • VESA mount

    CERTIFICATIONS

  • FCC
    CE

R15L100-RKA1

15" Rack Screen Mount
Winmate Application-Focused Rack mount display

Application-Focused Rack Mount Design

The design of the Rack Display Series allows you to quickly rack mount flat-screen monitors to server racks, cabinets, room controls, security monitoring, and other industrial solutions.


Winmate rack mount display with High definition display interfaces

HDMI, VGA Signal Interfaces

For easy integration to all embedded boards and systems, theRack Display Series comes with VGA, HDMI signal interfaces. Both interfaces are easy to use and support most industrial and commercial applications.


Winmate convenient on-screen user control Rack mount display

Intuitive Operations with the Touchscreen

Easy to connect to your equipment, this option is ideal for racks and consoles requiring touch screen capability. Convenient on-screen user control for the efficiency of the operator.


Winmate rack mount display with durable design with handles and metal housing

Suitable for Server Room Applications

With a pull-out drawer design, metal housing provides perfect protection from shock and drop. Convenient for portable outdoor, or applied in rack mount because of space-saving and durable design. Being able to be mounted to walls, shelves, and other vertical surfaces, Winmate’s Rack Mount Display can visualize data from network servers in a data room.

Display

Size

15.0 inches inches

Touch / Glass

Resistive Touch Screen (Default)
Protection Glass w/o Touch Function (Optional)
SAW Touch (Surface Acoustic Wave) (Optional)

Resolution

1024x768

Panel Brightness

350.0 nits nits

Contrast Ratio

800:1

View Angles

80,80,70,80

Display Color

16.2M Colors Colors

Active Area

304.128x228.096 mm mm

Environment

Operating Humidity

10% to 90% RH, Non-Condensing

Operating Temperature

0°C to 50°C

Storage Temperature

-10°C to 60°C

Length

Certification

Certification

CE, FCC

IO Ports

USB Port

1 x USB for Touch Screen

Video

1 x VGA (Default)
1 x HDMI (Optional)
1 x DVI (Optional)

Audio

Audio line in (3.5mm) (Optional)
2 x Speaker (Optional)

Power Input

Mechanical

Dimension

482 x 310 x 58.8 mm

Mounting

VESA Mount/Rack Mount

Enclosure

Metal Housing with Aluminum Bezel

Cooling System

Fanless Design

Accessory

Accessory

1 x VGA cable
1 x HDMI cable
100~240V AC to DC Adapter
Power Cord
Manual
VESA screws(Varies by product)

Optional Accessory

Remote Controller (Optional,Varies by product)

Power

Power Rating

12V DC in
24V DC in (optional)

Control

Button

5 Keys: - , + , Power , Esc , Enter

Rack Screen Mount Display Size 15.0 inches Touch / Glass Resistive Touch Screen Protection Glass w/o Touch Function (Optional) SAW Touch (Surface Acoustic Wave) (Optional) Resolution 1024x768 Panel Brightness 350 nits Contrast Ratio 800:1 View Angles 80,80,70,80 Display Color 16.2M Colors Active Area 304.128x228.096 mm Environment Operating Humidity 10% to 90% (non-condensing) Operating Temperature 0~50°C Storage Temperature -10~60°C Certification Certification CE, FCC IO Ports USB Port 1 x USB for Touch Screen Video 1 x VGA 1 x HDMI (Optional) 1 x DVI (Optional) Audio Audio line in (3.5mm) + 2 x Speaker (Optional) Mechanical Dimension 482 x 310 x 58.8 mm Mounting VESA Mount/Rack Mount Enclosure Metal Housing with Aluminum Bezel Cooling System Fanless Design Accessory Accessory 1 x VGA cable 1 x HDMI cable 100~240V AC to DC Adapter Power Cord Manual VESA screws(Varies by product) Optional Accessory Remote Controller (Optional,Varies by product) Power Power Rating 12V DC input Control Button 5 Keys: - , + , Power , Esc , Enter
